GOLD PLATED
FFC CABLES

Gold Plated FFC Cables

Designed for board to board interconnections, specially applicable for low contact resistance

Jetflex FFCs have very low profile, narrow width & very fine pitch, from 0.50mm, 1.00mm and 1.25mm pitch to suit your needs

Our FFCs are compatible with ZIF and LIF connector which saves time and helps in cost reduction

Types available from FFC Type A to Type L

Cable length (end to end) in mm is available from 30 mm to 9999 mm as per specification.

Exposed length in mm (left side / right side) is available as per specification.

Stiffener length in mm (left side / right side) is available as per specification

Pitch Availability 0.50mm 1.00mm 1.25mm
Conductor Size 0.035x0.30mm 0.05x0.65mm 0.05x0.80mm
Number of Conductors 8 – 90 4 – 50 4 – 50
Pitch Availability 0.50mm 1.00mm 1.25mm
Conductor Size 0.035x0.30 0.05x0.65 0.05x0.80
Number of Conductors 8 – 90 4 – 50 4 – 50
Types Available Type A - Type L illustrations – 12 illustrations side view
